Superior Features
Ideal Solution for Wide Areas
Provides ideal air conditioning solutions for wider areas with high heating and cooling capacity.
Anti Dust Filter
Collects the dust and particles at the environment.
Auto Restart
After power failures, air conditioner automatically restarts in the mode before the failure.
Jet Cool
The environment reaches desired comfort conditions within a very short period of time thanks to Jet Cool feature.
Hot Start
When the device is switched to heating mode, blowing is not performed until interior unit evaporator reaches the desired temperature. When sufficient temperature is achieved, only hot air is blown.
Program Timer
Practical usage is provided by switching the air conditioner on and off of at the adjusted time.
Specifications
Specifications
| T 410 C 42 kBTU/h | T 410 C 48 kBTU/h | |
|---|---|---|
| General Properties | ||
| Sleep mode | Yes | Yes |
| Additional electrical resistance | No | No |
| Auto restart | Yes | Yes |
| DC Inverter technology | No | No |
| Cooling liquid | R 410a | R 410a |
| Activated carbon filter | No | No |
| Anti bacterial filter | No | No |
| Anti dust filter | Yes | Yes |
| Anti freeze unit | Yes | Yes |
| Follow me | No | No |
| Ionizer | No | No |
| Jet Cool | Yes | Yes |
| Hot Start | Yes | Yes |
| Program timer | Yes | Yes |
| Capacity | ||
| Capacity (Cooling)kW | 12,3 | 14 |
| Air Flow Rate (Interior Unit)m³/h | 1.700 | 1.700 |
| Capacity (Heating)kW | 13,4 | 15,2 |
| Capacity (Heating)BTU/h | 45.800 | 52.000 |
| Capacity (Cooling)BTU/h | 42.000 | 48.000 |
| Efficiency | ||
| Efficiency Class (Cooling) | D | C |
| Efficiency Class (Heating) | E | C |
| COP (Efficiency Rate - Heating)W/W | 2,85 | 3,2 |
| EER (Efficiency Rate - Cooling)W/W | 2,61 | 2,89 |
| Dimensions (Interior Unit) | ||
| Heightmm | 310 | 310 |
| Widthmm | 830 | 830 |
| Depthmm | 830 | 830 |
| Weightkg | 37 | 37 |
| Dimensions (Exterior Unit) | ||
| Heightmm | 960 | 1.255 |
| Widthmm | 990 | 950 |
| Depthmm | 405 | 410 |
| Weightkg | 93 | 112 |
| Dimensions (Panel) | ||
| Yükseklikmm | 45 | 45 |
| Genişlikmm | 950 | 950 |
| Derinlikmm | 950 | 950 |
| Ağırlıkkg | 93 | 112 |
| Electrical Properties | ||
| Power Consumed (cooling)W | 4,72 | 4,8 |
| Power Consumed (heating)W | 4,63 | 4,75 |
| Operating Current (cooling)Amper | 8 | 8,2 |
| Operating Current (heating)Amper | 7,9 | 8,1 |
| Power supplyV,Hz,Ph | 400, 50, 3 | 400, 50, 3 |
| Sound Level | ||
| Interior UnitdB(A) | 46 | 46 |
| Exterior UnitdB(A) | 63 | 60 |
| Installation Information | ||
| Maximum copper pipe distancem | 15 - 25 | 15 - 25 |
| Maximum layer difference between interior-exterior unitsm | 7.5 - 10 | 7.5 - 10 |
